Right triangles show up all over the Math section, and most of their problems come down to just three tools: the Pythagorean theorem, two special triangles, and the SOH-CAH-TOA trig ratios. Memorize those and you can knock out these questions in seconds.

Where this lesson fits

You are here

→Lines, Angles, and Triangles →Circles →Coordinate Geometry

A right triangle is any triangle with one 90° angle (the little square corner). The side opposite that right angle — always the longest side — is the hypotenuse. The other two sides are the legs.

1. The Pythagorean theorem. For any right triangle with legs a and b and hypotenuse c:

a² + b² = c²

The hypotenuse is always c (alone on one side). If you know any two sides, you can solve for the third.

Loading…

A 3-4-5 right triangle: legs a and b, hypotenuse c opposite the right angle.

2. Special right triangles. Two triangles appear so often the test expects you to recognize them instantly:

45-45-90 triangle: the two legs are equal, and the hypotenuse = leg × √2. So the side ratio is 1 : 1 : √2. To go from leg to hypotenuse, multiply by √2; to go backward, divide by √2.
30-60-90 triangle: the sides are in ratio 1 : √3 : 2. The shortest side is opposite the 30° angle, the medium side (× √3) is opposite the 60° angle, and the hypotenuse (× 2, the longest) is opposite the 90° angle.

Loading…

A 30-60-90 triangle with sides in ratio 1 : √3 : 2.

3. Trigonometry — SOH-CAH-TOA. For one of the non-right angles (call it θ), label the sides relative to θ: the opposite side faces it, the adjacent side touches it (and isn't the hypotenuse). Then:

sin θ = opposite / hypotenuse (SOH)
cos θ = adjacent / hypotenuse (CAH)
tan θ = opposite / adjacent (TOA)

One handy fact the test loves: the sine of an angle equals the cosine of its complement. Since the two non-right angles add to 90°, sin(x°) = cos(90° − x°). So if sin A = 3/5, then cos B = 3/5 where A + B = 90°.

Most questions just ask you to plug into one of these three relationships. The hard part is correctly labeling opposite vs. adjacent for the angle in question — so always start by marking your angle and identifying the hypotenuse.

Loading…

Quick check

Check your understanding with a question from this topic:

In a 45-45-90 triangle, the hypotenuse has length 10√2. What is the length of each leg?

Your answer:

Enter a whole number, fraction (e.g. 3/4), or decimal (e.g. .75).

Worked examples

Example 1

A right triangle has legs of length 9 and 12. What is the length of the hypotenuse?

Example 2

In a 30-60-90 triangle, the side opposite the 30° angle has length 5. What is the length of the hypotenuse?

Example 3

In right triangle ABC, the right angle is at C. If sin A = 7/25, what is the value of cos B?

Common pitfalls

Treating a leg as the hypotenuse

The Pythagorean theorem requires c to be the hypotenuse (opposite the right angle). If a problem gives you the hypotenuse and one leg, you must SUBTRACT: leg² = c² − other leg², not add.

Mixing up the special-triangle ratios

Students confuse √2 (for 45-45-90) with √3 (for 30-60-90). Remember: equal legs → √2; the 30-60-90 has a √3 for its medium side and a 2 for the hypotenuse.

Mislabeling opposite vs. adjacent

Opposite and adjacent are defined relative to the angle you're using. Always circle your angle first; the side touching it (other than the hypotenuse) is adjacent, the side across from it is opposite.

Forgetting the sin/cos complement rule

When a problem gives sin of one angle and asks for cos of another in the same right triangle, check if the angles are complementary — sin x = cos(90 − x) lets you answer instantly without finding any sides.

Key takeaways

Pythagorean theorem: a² + b² = c², where c is always the hypotenuse.
45-45-90 sides are in ratio 1 : 1 : √2; 30-60-90 sides are 1 : √3 : 2.
SOH-CAH-TOA: sin = opp/hyp, cos = adj/hyp, tan = opp/adj — labeled relative to your chosen angle.
For complementary angles, sin x = cos(90 − x).
Memorize the common Pythagorean triples (3-4-5, 5-12-13, 8-15-17) to skip arithmetic.
